Size |
|
|
Dimensions |
Approx. 338 mm (W) x 188 mm (D) x 173 mm (H) (including keybord LCD unit) |
|
Weight |
Approx. 4.6 kg (including keybord LCD unit, excluding Li-ion Battery) |
|
Printing |
|
|
Print method |
Thermal Transfer |
|
Compatible tubes *1 |
Inner diameter: Φ2.5 mm – Φ6.5 mm |
|
Thickness: 0.5 mm |
|
|
Material: PVC |
|
|
Print head |
454 dot/360 dpi (for labels) |
|
86 dot/360 dpi (for tubes) |
|
|
High resolution mode: max. 720 dpi × 360 dpi (when connected to a computer) *2 |
|
|
Print height |
Label: max. 32 mm (when using 36 mm tape) *3 |
|
Tube: max. 6 mm (when using Φ6.5 mm tube) *3 |
|
|
Print speed |
Label: |
|
AC Adapter: max. 60 mm/sec. |
|
|
Battery: 20 mm/sec. – 60 mm/sec. (varies depending on the tape width) |
|
|
Tube: |
|
|
max. 40 mm/sec. |
|
|
Actual print speed varies depending on the conditions. |
|
|
Cassette |
Brother TZe tape cassette (3.5 mm, 6 mm, 9 mm, 12 mm, 18 mm, 24 mm, 36 mm widths) |
|
Brother HSe tube cassette (5.8 mm, 8.8 mm, 11.7 mm, 17.7 mm, 23.6 mm widths) |
|
|
Brother FLe label cassette (21 mm x 45 mm) |
|
|
Brother TR ribbon cassette (12 mm width) |
|
|
No. of lines |
▪ TZe tape cassette |
|
36 mm tape: 17 lines; 24 mm tape: 13 lines; 18 mm tape: 10 lines; 12 mm tape: 6 lines; 9 mm tape: 4 lines; 6 mm tape: 3 lines; 3.5 mm tape: 1 lines |
|
|
▪ HSe tube cassette |
|
|
23.6 mm tape: 12 lines; 17.7 mm tape: 10 lines; 11.7 mm tape: 6 lines; 8.8 mm tape: 4 lines; 5.8 mm tape: 2 lines |
|
|
▪ PVC tube |
|
|
Φ6.5 mm tube: 2 lines; Φ6.0 mm tube: 2 lines; Φ5.0 mm tube: 2 lines; Φ4.0 mm tube: 2 lines; Φ3.5 mm tube: 2 lines; Φ3.0 mm tube: 2 lines; Φ2.5 mm tube: 1 line |
|
|
Memory (local files) |
|
|
File storage |
max. 99 files |
|
Power Supply |
|
|
Adapter |
AC adapter (AD9100ESA): 24 V |
|
Battery (Optional) |
Li-ion Battery (PA-BT-4000LI): 14.4 V |
|
Auto Power-off |
Li-ion Battery (PA-BT-4000LI): 30 min |
|
AC adapter (AD9100ESA): Off |
|
|
Interface |
|
|
USB |
Version 2.0 Full Speed |
|
Wi-Fi |
▪ Wireless Direct: IEEE 802.11n |
|
▪ Ad-Hoc mode: IEEE 802.11b |
|
|
▪ Infrastructure mode: IEEE 802.11b/g/n |
|
|
▪ WPS 2.0 |
|
|
Other |
|
|
Operating temperature / humidity |
▪ TZe engine |
|
When running: between 10°C and 35°C / between 20% and 80% |
|
|
max. wet bulb temperature: 27°C |
|
|
▪ Tube engine |
|
|
When running: between 15°C and 35°C / between 20% and 80% |
|
|
max. wet bulb temperature: 27°C |
